Dimensions
- A Grip diameter
- Min 1.5 – Max 2.5 in
- C
- 1.335 in
- D
- 1.468 in
- F Flange diameter
- 5.937 in
- G
- .500-20 in
- H
- 3.128/3.123 in
- J
- 0.688 in
- K
- .250-20 x 1.500 in
- L
- 1.843 in
- M
- 0.727 in
- P
- 0.376 in
- Q
- 1.468 in
- R
- 0.218 in
- S
- 0.406 in
- T
- 0.897 in
- U
- 304 (3/32 X 1/2) in
- V
- 2 in
Dimensions
- A Grip diameter
- Min 1.5 – Max 2.5 in
- C
- 1.335 in
- D
- 1.468 in
- F Flange diameter
- 5.937 in
- G
- .500-20 in
- H
- 3.128/3.123 in
- J
- 0.688 in
- K
- .250-20 x 1.500 in
- L
- 1.843 in
- M
- 0.727 in
- P
- 0.376 in
- Q
- 1.468 in
- R
- 0.218 in
- S
- 0.406 in
- T
- 0.897 in
- U
- 304 (3/32 X 1/2) in
- V
- 2 in
Documentation
Documentation
Download 3D Files
Download 3D Files
- Regular price
- $1,109.00
