Dimensions
- A Grip diameter
- Min 3.5 – Max 5.5 in
- C
- 1.59 in
- D
- 3.012 in
- F Flange diameter
- 9 in
- G
- 1.500-12 in
- H
- 4.753/4.748 in
- J
- 0.75 in
- K
- .375-16 x 1.750 in
- L
- 2.51 in
- M
- 0.969 in
- N
- 2.063 in
- P
- 1.942 in
- Q
- 3.437 in
- R
- 0.5 in
- S
- 1.25 in
- T
- 1 in
- U
- 3.75 in
Dimensions
- A Grip diameter
- Min 3.5 – Max 5.5 in
- C
- 1.59 in
- D
- 3.012 in
- F Flange diameter
- 9 in
- G
- 1.500-12 in
- H
- 4.753/4.748 in
- J
- 0.75 in
- K
- .375-16 x 1.750 in
- L
- 2.51 in
- M
- 0.969 in
- N
- 2.063 in
- P
- 1.942 in
- Q
- 3.437 in
- R
- 0.5 in
- S
- 1.25 in
- T
- 1 in
- U
- 3.75 in
Documentation
Documentation
Download 3D Files
Download 3D Files
- Regular price
- $2,501.00
