A Min_Cust. piece part grip dia :  1.25
A Max_Cust. piece part grip dia :  2
B :  5.937
D :  1.012
F _ Flange diameter :  1.3375
Show more dimensions
G :  .438-20
H :  3.128/3.123
J :  0.687
K :  .250-20 x 1.50
L :  1.51
M :  0.59482
P :  0.3
R :  2.5
S :  2
T :  0.406
U :  0.25767
V :  1.218
md-style-mandrels;md-style

MD Style Mandrel Chuck

$1,088.00
A Min_Cust. piece part grip dia :  1.25
A Max_Cust. piece part grip dia :  2
B :  5.937
D :  1.012
F _ Flange diameter :  1.3375
Show more dimensions
G :  .438-20
H :  3.128/3.123
J :  0.687
K :  .250-20 x 1.50
L :  1.51
M :  0.59482
P :  0.3
R :  2.5
S :  2
T :  0.406
U :  0.25767
V :  1.218

Documentation

Data Sheet

2D Drawing

3D Drawing

Download 3D Files

Creo Parametric (.asm)

Solidworks (.sldprt)

STEP (.stp)

ACIS (.sat)

Parasolid (.x_t)

IGES (.igs)

$1,088.00
