Dimensions
- A Grip diameter
- Min 6.25 – Max 13 in
- B Length
- 3.25 in
- Actuation
- Draw bar operation
- C
- 6 in
- D
- 1.124 in
- E
- 1 in
- F Flange diameter
- 9 in
- G
- 2.75 in
- H
- 0.5 in
- J
- 1.000-8 in
- K
- 1.375 in
- L
- 3.875 in
- M
- 0.75 in
- N
- 7.125 in
- P
- (3) .375-16 in
- Q
- (3) .500-13 in
- S
- 1.5 in
- T
- 1 in
- U
- 1.875 in
- V
- 2.375 in
Dimensions
- A Grip diameter
- Min 6.25 – Max 13 in
- B Length
- 3.25 in
- Actuation
- Draw bar operation
- C
- 6 in
- D
- 1.124 in
- E
- 1 in
- F Flange diameter
- 9 in
- G
- 2.75 in
- H
- 0.5 in
- J
- 1.000-8 in
- K
- 1.375 in
- L
- 3.875 in
- M
- 0.75 in
- N
- 7.125 in
- P
- (3) .375-16 in
- Q
- (3) .500-13 in
- S
- 1.5 in
- T
- 1 in
- U
- 1.875 in
- V
- 2.375 in
Documentation
Documentation
Download 3D Files
Download 3D Files
- Regular price
- $2,093.00
